Product Description
Square Frame Circular Truss 4 Segments 6.56 FT 2m
Description
XT-CSQ656-4X90 Square Framed Circular Truss; Square Framed Circular Truss (4 Segments), 6.56FT (2m)
ProX Truss has the most trusted staging support systems in the industry, and is built to the highest standards of safety and performance. It's a rugged yet lightweight trussing solution perfect formobile DJs, bands, outdoor performances, nightclubs, live mobile productions, or permanent installations.
At the heart of the system is square circular truss that utilize a standard conical connector system, which easily mates with other brands of truss of the same size and connector style, and is available in a variety of lengths to suit your designs. It also works with different types of corners, base plates, connectors and accessories that add stability while expanding on limitless configurations.
Tolerance Free Standard Conical connector
Main tube wall thickness of .08in / 2mm
Constructed to the highest safety ratings by certified welders
XT-SQ SERIES DIMENSIONS
4X 90degree Sections
Square Framed Circular Truss (4 Segments), 6.56FT (2m)
Shipping Weight: 76Lbs
6.56ft 2.0m outside dimension
4.56 Inside dimension
Main Tube: 2in / 50mm
Braces: .75in / 20mm / 3/4"
Material: EN-AWT6 6082 Aluminum
Includes connecting hardware set.
All ProX Truss products are 100% compatible to connect along with many other manufacturers.
Specifications
To Fit
Standard Size Truss Configurations.
Square Frame Circular Truss (4 Segments), 6.56FT (2m)
- Shipping Weight: 76.00 lbs
